Apollo/Nice Gate Openers, Accessories and Parts
Apollo Gate Openers
Headquartered In San Antonio, Texas, Apollo has been a trusted name in the gate opener industry
since 1984. Known for their reliability and efficiency it is no wonder why they are the U.S. leader in low
voltage automated gate systems with solar power options.
Let Gate Crafters and Apollo add safety and security to your home today!
Nice Apollo Gate Operator Feature Chart
|
 |
 |
|
 |
 |
 |
| Features |
Residential |
Commercial |
| Model Number |
TITAN 912 |
1500/1600 |
1550/1650 |
Vanguard 3501/3601 |
7251 |
7351 |
| Description |
18VDC Residential & Farm Gate Operator |
18VDC Residential & Farm Gate Operator |
18VDC Residential Gate Operator |
18VDC Commercial Gate Operator |
18VDC Commercial Gate Operator |
18VDC Commercial Gate Operator |
| Operator Type |
Swing |
Swing |
Swing |
Swing |
Slide |
Slide |
| Power Supply |
18VDC |
18VDC |
18VDC |
18VDC |
18VDC |
18VDC |
| Open/Close Time |
14 - 16 seconds
(adjustable) |
14 - 16 seconds
(adjustable) |
14 - 16 seconds
(adjustable) |
12 - 20 seconds
(adjustable) |
1 ft. per second |
1 ft. per second |
| Duty Cycle |
50% AC
Varies for Solar |
50% AC
Varies for Solar |
50% AC
Varies for Solar |
50% AC
Varies for Solar |
50% AC
Varies for Solar |
50% AC
Varies for Solar |
| Operating Temperature |
-4°F to +122°F |
-4°F to +122°F |
-4°F to +122°F |
-4°F to +122°F |
-4°F to +122°F |
-4°F to +122°F |
| Max. Gate Weight |
1,000 lbs. |
600 lbs. |
600 lbs. |
1,000 lbs. |
800 lbs. |
800 lbs. |
| Max. Gate Length |
20 ft. |
16 ft. |
16 ft. |
20 ft. |
25 ft. |
25 ft. |
| Solar Compatible |
Yes
Max. 30W |
Yes
Max. 40W |
Yes
Max. 40W |
Yes
Max. 50W |
Yes
Max. 40W |
Yes
Max. 40W |
| Gate Operator Class |
Class I & II |
Class I & II |
Class I & II |
Class I & II |
Class I & II |
Class I & II |
| Max. Degree |
110° |
110° |
110° |
117° |
x |
x |
| User Controls |
936, Mercury 360 or 1050 Control Board |
636 Control Board
(Not UL 325 Certified) |
Mercury 360 or 1050 Control Board |
1050 Control Board |
1050 Control Board |
1050 Control Board |
| Wire Specification* |
16 Gauge |
16 Gauge |
16 Gauge |
16 Gauge |
16 Gauge |
4 - 14 Gauge |
| Limited Warranty |
3 Year Warranty |
3 Year Warranty |
3 Year Warranty |
3 Year Warranty |
3 Year Warranty |
3 Year Warranty |
*Determined by the distance from the power source to the operator.
GateCrafters.com is the only company that makes an Apollo gate opener truly DIY
Access Included
at
Gate Crafters
Gate Crafters provides two remotes with every Apollo gate opener, no remotes are provided by the factory and are normally purchased separately. Gate Crafters also provides battery charging with every Apollo gate opener, something the factory also does not include but is necessary.
No Welding
at
Gate Crafters
Apollo gate openers are commercial quality gate openers and as such most are made to be installed using welding. Gate Crafters takes away this need by providing special brackets or pre-welding brackets in our fabrication shop.
OUR TECH/INSTALLATION SUPPORT HOURS: 7 DAYS 9am-9pm
