The GTO/PRO GP-SL050 is a revolution in the gate opener business. It has major advancements in control board intellect, limit positioning
and power supply. It is used for residential applications.
- Gate Materials: Wood, Steel, Aluminum, Vinyl, Panel, Ornamental, Chain Link, and others.
- Weight and length: Up to 32', max opening of 27' and 800 lbs
- Power: 120V @60Hz & Two 12 volt U1, 230A cold crank amp batteries (required, but not included).
- Power Wire Specification: 16 gauge wire
(purchased separately) with 1,000 foot max length from transformer to control board.
- Movement Method: Chain
- Mounting : Pad Mount
- Warranty: 5-year control board/ 7-year component limited warranty. (Click Here for Warranty Pros and Cons)
|
|
|
|
|
GateCrafters.com offers more expert assistance than anyone. If you need help deciding if this gate opener has the abilities that are
right for your gate we have live application specialists available 9am - 9 pm EST 7 days a week or try our exclusive gate opener
recommendation tool 24 hours/day.
|
|
|
|
|
|
The GP-SL050 is an intuitive and highly intelligent system for residential applications. It is a pad mount operator. Due the 120V needed
to power the system a professional installer is recommended for installation.
Programming is a breeze using the JOG feature which allows the installer to move the gate leafs back and forth during the programming
sequence to position the gate in the right end points thus eliminating guessing and reprogramming. During operation disturbances in the travel
of the gate will not interfere with stop point counting because of an inherent ABS system. One of the main features is the battery backup,
supplying approximately 100 cycles with the minimum battery at full charge.
The system can be used with many GTO accessories including loops and guard station controls making this both the installer's choice
and the end users choice in gate automation.
|
|
View Inside: Click to Enlarge |
|
|
|
|
|
GateCrafters.com is the DIY factor. GateCrafters.com further adds to most of our gate openers for easier DIY installation. We
have developed exclusive components (example: easy adjustable mounting brackets), customized instructions, and offer a full spectrum of
accessories to truly cover all aspects of the installation of your gate opener. In addition we have the largest staff of factory trained technicians
in the US.
|
|
|
|
|
|
|
Included with Gate Opener from Manufacturer
|
Top of Page
|
- Sliding Operator Motor and Housing
- Control Board
- 20' of #41 Chain
|
- Warning Signs
- Hardware
- Installation Manual
|
|
|
Gate Crafters.com Exclusive Product & DIY
Additions
|
Top of Page
|
|
2) gate opener remotes
1) gate opener receiver
Order specific customized accessory wiring instructions
360 degree accessories - we can take you through exit, entry, safety, power, and all other minute details to create a fully rounded
kit.
Free 24/7/365 Installation Support
Free 7 day/week Technical Support
Largest Number of Certified Techs in America
Free assistance to find the right gate opener for your gate
Free systems design assistance to match the right accessories to fit your needs.
Extremely competitive pricing
Free shipping on all accessories purchased with a gate opener
We stock all replacement parts
Many brands of many types of accessories, enough to handle just about any operational situation you can imagine
|
|
|
|
|
|
GateCrafters.com has actual experience. We have a testing area, we have factory and internal training courses, we build gates and
have our own gates that are automated, we attended all industry trade shows in multiple countries and are a member of the AFA, and we
pay visits to our chosen manufacturers' factories. All these factors are what have lead to us having so many exclusive additions. When you
see and actually use as many products as we have you tend to have many ideas for minor changes that have major impacts. We acted on
these ideas and have utilized them to help thousands of customers automate their gates.
|
|
|
|
|
|
|
|
The following tools and supplies are suggested in the manufacturer manual for optimal installation. They are not provided by
GateCrafters, however, most tools are available at local hardware stores for purchase or rental.
- Please refer to manual for Tools Needed
Depending on the type of gate, power supply and contributing environmental factors additional tools or supplies may be needed. Please
review the product manual associated with this gate opener model for further details.
|
|
Words from Senior Application Engineer, Anthony
Gaeto
|
Top of Page
|
"The GTO PRO GP-SL050 is truly a great step forward in gate opener technology. The battery back-up system is one of the top features of
this system. Most 110V AC units cannot have battery backup without spending hundreds of dollars more. The GP-SL050 all you need are
the batteries, the rest is built into the system.
Another great feature is the brushless motor; because of the use of this technology the system can know its position at all times and will not
wear down the same as standard motors. Most gate openers, if power is cut mid-cycle or some other type of interruption happens the gate
opener becomes confused on its position and needs to complete a cycle before going to normal operation. The GP-SL050 has a location
system built in so it will always know its position.
There are a lot of other great features of this system; like the audible and visual diagnostics, the plug in loop detectors, the power receptacles
in the box, and so much more but I did have to point out in detail the ease of programming. It has a JOG system. What this means is if during
the limit setting you are not in the right position to set your limit you can push a button and the motor will turn slightly in either direction to get
it positioned correctly. This will save a lot of headaches.
GTO, inc. does recommend that a professional installs this unit and GateCrafters.com supports this policy. GateCrafters.com is however still
available for any installation or technical support the installer may need. Gate Crafters has years of experience with GTO inc. openers as well
as many other brands and accessories and is readily available 7 days a week.
GateCrafters.com is dedicated to getting the right gate opener for your gate. As more gate openers are being made economically feasible
and easy to maintain, the selection is going to grow ever wider. That's where GateCrafters.com comes in. We have extensive amounts of
educational material on our website to help you become an informed consumer. We also have our factory-trained representatives standing
by to answer all your gate and gate opener questions. The combination of our customers passion for home improvement and
GateCrafters.com's wealth of knowledge is a perfect match and cannot be duplicated."
|
|
As part of one of GateCrafters.com's constant quality checks and knowledge updates. I personally go to visit the factories in which the
products we sell are made. I made 6 visits to the GTO Inc. US facility, most recently in Februrary 2009. My visits accumulated a
considerable period of time visiting because they were not only to tour the facility and meet employees, but also for authorized factory
training. During training I received a certificate (Click here to view) and a score of 100% on the Factory Certified training exam.
|
Manual: SL050 Single Slide Gate Opener Manual
QB ID: GP-SL050.
|
