The Estate Swing 433 MHz 2-Channel Receiver (433ESREC) can control two separate devices or two different relays on a control board and can learn up to 400 codes. A common application is using the receiver to control two devices in a three-car garage. Typically, this type of garage has two separate garage door openers, and a single receiver can be used to control both, with each door operated by a separate button on the remote.
Another option is using the two relays to control two separate terminals on a single gate opener. Many gate openers include one terminal for automated open and close functions and another terminal for partial opening or an open-only function during re-closing without stopping. In this setup, a second button on the remote can be used to control the additional function.
This receiver is also available as a plug-in receiver for Estate Swing gate openers.
Gate Crafters offers more expert assistance than anyone.
If you need help deciding if this gate opener has the abilities that are right for your gate we have live application specialists available 9am - 9 pm EST 7 days a week or try our exclusive gate opener recommendation tool 24 hours/day.
- Compatible with all 24-volt gate openers when wired. (Will require a 12-volt transformer - NOT INCLUDED)
Easy Wiring:
There are four or six wires to connect, depending on whether you are using one or two channels. Two wires are for power, which can be AC or DC (12 - 24V). If you cannot locate a power source, most gate openers have a battery you can tap into, you can connect the receiver to a transformer. (Check your junk drawer; many old transformers from other electronics may fall within the generous voltage range supported by this receiver.)
The remaining two wires are used to close a circuit. On a garage door opener, simply locate the two terminals used by the wall-mounted control button.
Strong Range:
This is one of the standout features of this receiver. The rated range is 300 feet, and in many cases, it can exceed that distance.
Learn Button Programming:
Programming is quick and simple. Press the learn button on the receiver until the indicator light turns on. Then press the button on the remote you wish to use. The light will blink and turn off, programming is complete. Repeat this process for additional remotes or buttons. The receiver can learn up to 400 remotes.
Versatility:
Thanks to its simple design, this receiver can be used for a wide variety of applications. On Estate Swing gate operators, there is a second open-command terminal for partial openings. This receiver allows a dual-button remote to control both full and partial gate openings.
On Apollo and GTO gate operators, which feature open-only terminals, this receiver can be used to create safer automation for multiple remote users by allowing them to open the gate while auto-close handles closing. This is ideal for condos and other public entrances, as it prevents users from accidentally reversing the gate into another vehicle.
For accessories that are not wireless, the 433UNIADP 433 MHz adapter can be paired with this receiver to convert them into wireless devices. Additionally, the receiver offers both normally open and normally closed connections, allowing it to either open or close a circuit wirelessly. Over time, hundreds of customers have found many creative and practical uses for this device.
Gate Crafters has the resources you need.
How do you use your gate opener system once you get it? Gate Crafters is the only retailer to give a real answer to this question. We have develop videos for installing many of our gate openers and products and write DIY focused manuals for most gate openers and have individual instructions for each accessory to be installed with each gate opener.
- Frequency: 433 MHz
- Channels: 2
- Memory Capacity: Up to 400 remote codes
- Operating Range: Rated up to 300 feet
- Power Input: 12 - 24V AC or DC
- Wiring:
- 4 wires (single channel)
- 6 wires (dual channel)
- Relay Type: Normally Open (NO) and Normally Closed (NC)
- Model Number: 433ESREC
- (1) Estate Swing 433 MHz 2 Channel Receiver (433ESREC)
For over a decade, Gate Crafters has been the premier online retailer of gate openers and accessories. With our extensive technical and installation expertise, we are authorized to serve the DIY market. We believe customers should have the opportunity to take pride in their projects, whether installing or troubleshooting a gate opener. Everyone deserves the option to enjoy high-quality products without the need to hire help.
At Gate Crafters, we empower you to install confidently by providing access to our trained technical staff seven days a week from 9 AM to 9 PM EST. By choosing to DIY your gate opener system, you can save thousands of dollars over its lifetime while gaining valuable knowledge about your installation and how the system operates. This understanding will make it easier to troubleshoot any issues and perform routine maintenance in the future.
Gate Crafters is the DIY factor.
Gate Crafters further adds to most of our gate openers for easier DIY installation. We have developed exclusive components (example: easy adjustable mounting brackets), customized instructions, and offer a full spectrum of accessories to truly cover all aspects of the installation of your gate opener. In addition we have the largest staff of factory trained technicians in the US.
- Order specific customized accessory wiring instructions
- 360 degree accessories - we can take you through exit, entry, safety, power, and all other minute details to create a fully rounded kit.
- Free 24/7/365 Installation Support
- Free 7 day/week Technical Support
- Largest Number of Certified Techs in America
- Free assistance to find the right gate opener for your gate
- Free systems design assistance to match the right accessories to fit your needs.
- Extremely competitive pricing
- Free shipping on all accessories purchased with a gate opener
- We stock replacement parts
- Many brands of many types of accessories, enough to handle just about any operational situation you can imagine
Gate Crafters has actual experience.
We have a testing area, we have factory and internal training courses, we build gates and have our own gates that are automated, we attended all industry trade shows in multiple countries and are a member of the AFA, and we pay visits to our chosen manufacturers' factories. All these factors are what have lead to us having so many exclusive additions. When you see and actually use as many products as we have you tend to have many ideas for minor changes that have major impacts. We acted on these ideas and have utilized them to help thousands of customers automate their gates.
The following tools and supplies are suggested in the manufacturer manual for optimal installation. They are not provided by Gate Crafters, however, most tools are available at local hardware stores for purchase or rental.
Please refer to the Installation Manual for Tools Needed.
Depending on the type of gate, power supply and contributing environmental factors additional tools or supplies may be needed. Please review the product manual associated with this gate opener model for further details.
