Viking Gate Openers, Accessories and Parts
Viking Access Systems Gate Openers & Gate Operators
Viking Access Systems is known for developing advanced, high-efficiency gate operators for residential and commercial applications. Its product lineup includes swing gate operators, slide gate operators, underground gate operators, and solar gate operators, providing solutions for a wide range of automatic gate installations.
Viking gate operators are engineered for reliable, efficient, and safe operation. Key features include 100% continuous-duty operation, soft start and soft stop, intelligent obstruction sensing, adaptive and self-learning technology, battery backup, and protection against lightning, short circuits, and power surges. Viking operators also meet UL325 and UL991 safety requirements, depending on the model.
At GateCrafters, we offer a selection of Viking gate openers, gate operators, and accessories for residential and commercial gate automation. With our knowledgeable technical support, installation resources, and experience in gate automation, we help customers choose the right Viking swing, slide, solar, or underground gate operator for their specific application.
Viking Gate Operator Feature Chart
|
 |
 |
 |
 |
 |
 |
 |
 |
| Features |
Residential |
Commercial |
| Model Number | E-4 | R6 | K2 | G5 | X390 | F1 | L3 | H10 |
| Application | Residential | Residential | Residential | Residential & Commercial | Residential & Commercial | Residential & Commercial | Residential & Commercial | Residential & Commercial |
| Operator Type | Swing | Swing | Slide | Swing | Swing | Swing | Slide | Slide |
| Power Supply | 24VDC | 24VDC | 24VDC | 24VDC | 24VDC | 24VDC | 24VDC | 24VDC |
| Cycle Speed | 12 - 16 seconds | 13 - 16 seconds | 12” per second | 15 - 18 seconds | 10 - 13 seconds | 13 - 16 seconds | 12” per second | 12” per second |
| Cycles per Hour | 100% Continuous Cycle | 100% Continuous Cycle | 100% Continuous Cycle | 100% Continuous Cycle | 100% Continuous Cycle | 100% Continuous Cycle | 100% Continuous Cycle | 100% Continuous Cycle |
| Operating Temperature | -20°F to 160°F | -20°F to 160°F | -20°F to 160°F | -20°F to 160°F | -20°F to 131°F | -20°F to 160°F | -20°F to 160°F | -20°F to 160°F |
| Max. Gate Weight | 850 lbs.* | 700 lbs. | 700 lbs. | 2,000 lbs.* | 600 lbs. | 1,500 lbs.* | 1,600 lbs. | 2,200 lbs. |
| Max. Gate Length | 16 ft. | 14 ft. | 30 ft. | 18 ft. | 14 ft. | 16 ft. | 60 ft. | 75 ft. |
| Solar Compatible** | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Battery Backup | Up to 400 Continuous Cycles | 400 Full Continuous Cycles | 100 Full Continuous Cycles | 400 Full Continuous Cycles | Up to 400 Continuous Cycles | 400 Full Continuous Cycles | 100 Full Continuous Cycles | 100 Full Continuous Cycles |
| Max. Degree | 110° | 120° | x | 135° | 120° | 120° | x | x |
| Operator Class | Class I | Class I | Class I | Class I, II, III, IV | Class I, II, III, IV | Class I, II, III, IV | Class I, II, III, IV | Class I, II, III, IV |
| Wire Specification | 14 - 16 Gauge | 10 Gauge | 10 Gauge | 10 - 16 Gauge | 10 - 16 Gauge | 10 Gauge | 10 Gauge | 10 Gauge |
| Limited Warranty | 3 Year Warranty | 5 Year Warranty | 5 Year Warranty | 3 Year Warranty | 3 Year Warranty | 5 Year Warranty | 5 Year Warranty | 5 Year Warranty |
*As the gate gets longer, it must weigh less.
**Solar ECU sold separately. Please refer to your manual to confirm compatibility.
Viking Gate Openers and Parts
Access Included
at
Gate Crafters
Gate Crafters is in business to provide high-quality, professional-grade gate openers to the DIY consumer. Customers purchase with us because of our easy DIY installation and simple instructions. Viking Access Systems with high-quality products stands out as a superior option, listed by UL and ETL certifications.
No Welding
at
Gate Crafters
Everyone's lifestyle is different. Do you have many visitors, travel a lot, receive a lot of deliveries, have service people at the house, have pets or livestock, need high security, or other needs? Gate Crafters has accessories to fill all your needs and the know-how to put it all together to work with the gate opener you choose. check options here
OUR TECH/INSTALLATION SUPPORT HOURS: 7 DAYS 9am-9pm
